| HEAVY DUTY |
| CYLINDER ARM |
| TWO NEEDLE |
| DROP FEED, NEEDLE FEED (COMPOUND FEED) |
| ALTERNATING PRESSER FEET |
| LOCKSTITCH MACHINE |
| with CENTRA-LUBEŽ-SEMI-AUTOMATIC LUBRICATION SYSTEM |
| LARGE
VERTICAL AXIS ROTARY HOOK AND BOBBINS |
| REVERSE
FEED |
| SAFETY
CLUTCH |
Specifications
|
|
387RB-2 |
| Speed, Max (S.P.M.) |
: |
2500* |
| Clearance Under Foot |
: |
11/32" (8.5mm) |
| Needle Bar Stroke |
: |
1-5/16" (33mm) |
| Needle |
: |
135x17 |
| Stitch Length Max. |
: |
@4 s.p.i. (5mm) |
| Bobbin - Metal |
: |
15041 |
|
- Pre-wound |
: |
S |
| Hook |
: |
13719 |
| Bed Size |
: |
3 7/32" dia. x 13" (82mm x 330mm) |
| Work Space |
: |
10" (258mm) |
| Stitch Type |
: |
301 |
| Standard Needle Spacing |
: |
1/8", 1/4", 3/8", 1/2" |
*Speed depends on thread, material and operation.
Applications
- For sewing light to heavy-weight fabric leather, vinyl, upholstery, synthetics,
canvas and various laminated and coated materials.
- Designed for stitching tubular and curved work.
- Suitable for sewing such products as caps, cushions, boots, shoes, auto, boat and
furniture upholstery, tarpaulins, covers, sails, tents, awnings, umbrellas, tops, bags,
luggage, handbags, travelware, accessories, sports and camping equipment, wearing apparel,
orthopedic appliances, slippers, filters, etc.
Features
- Two needle mechanism readily makes two parallel lines of stitches.
- Large vertical axis rotary hooks and bobbins assure longer operation between bobbin
changes.
- Compound feed, walking foot mechanism assures even feeding of several piles or of
slippery materials.
- Centra-LubeŽ semi-automatic lubrication system
- Reverse feed
- Safety clutch prevents the hook from being damaged.
- Simple adjustment permits the raising and lowering of the center foot which allows
for sewing different thicknesses of material.
- Various needle gauges available.
